P2.5 Outdoor LED Screen Diecast Magnesium Specification

Water Proof
Yes, IP65

Power Supply
Built-in low voltage power supply

Body Material
Diecast Magnesium Alloy

Power Rating
Max 800 900W per cabinet | Average 250 350W per cabinet (960 960 P2.5 Outdoor Die-Cast Magnesium Cabinet).

Product Type
P2.5 Outdoor LED Screen Diecast Magnesium

Display Function
Video/Animation/Text Display

Application
Ideal for high-resolution outdoor advertising, commercial facades, highway billboards, and public information displays requiring bright and weatherproof performance.

Working Voltage
AC 100-240V, 50/60Hz

Screen Dimension
Customized

IP Rating
IP65

Working Temperature
-20 C ~ +60 C Celsius (oC)

Pixels
2.5mm Pixel Pitch Pixel (P)

Frame
Diecast Magnesium Alloy

Size
960 x 960mm per cabinet

Usage & Applications
Perfect for high-brightness outdoor advertising, billboards, and commercial facade displays in all weather conditions.

Rated Voltage
AC 110V 240V, 50/60Hz (Wide voltage input for stable outdoor operation). Volt (V)

Operating Temperature
-20 C to +60 C, designed for stable outdoor performance in extreme heat, rain, and dusty environments. Celsius (oC)

Color
Full Color RGB

Dimension (L*W*H)
960X960X100 Millimeter (mm)

Warranty
2.years

Display Type
Outdoor Fixed Installation, Full-Color SMD (RGB) LED Display with Die-Cast Magnesium Cabinet.

Phase
Single Phase (AC 110V 240V, 50/60Hz); Three Phase recommended for large screen installations.

Frequency
3840 Hertz (HZ)

Rated Current
Approx. 4.0 4.5 Amps per cabinet (at 220V, Max Load) for P2.5 Outdoor 960 960 Die-Cast Magnesium Cabinet. Volt (v)

Material
Die-Cast Magnesium Cabinet with Weatherproof Outdoor SMD Modules and Anti-Corrosion Coating.

Conductor
High-purity copper internal power and signal conductors with gold-plated connector pins for stable outdoor performance.

Features
High-brightness P2.5 outdoor LED display with lightweight 960 960 die-cast magnesium cabinets delivering durable, seamless, and weatherproof performance.

Service Access
Front & Rear Maintenance

Average Power Consumption
280W/m

Module Resolution
192 x 192 pixels (per module)

Grey Scale
14-16 bit

Control System
Novastar/Colorlight/Linsn Supported

Input Signal
HDMI, DVI, VGA, SDI, USB, LAN

Viewing Angle
Horizontal 140, Vertical 140

Brightness
5000-5500 nits

Life Span
>100,000 hours

Refresh Rate
1920Hz

Cabinet Weight
Approx. 7.5 kg/panel

Max Power Consumption
800W/m

P2.5 Outdoor LED Screen Diecast Magnesium Trade Information

Minimum Order Quantity
30 Square Foots

Supply Ability
5000 Square Foots Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About P2.5 Outdoor LED Screen Diecast Magnesium

P2.5 Outdoor LED Display 960960 Die-Cast Magnesium Cabinet (With 320160 Lampro Modules)

Product Description

The P2.5 Outdoor LED Display 960960 Die-Cast Magnesium Cabinet Series is a high-brightness, fine-pitch outdoor solution designed for superior clarity and durability. Built with lightweight yet strong die-cast magnesium cabinets, this series ensures excellent heat dissipation, corrosion resistance, and structural stability for long-term outdoor installations.

Each 960960 cabinet is integrated with 320160mm Lampro outdoor modules, delivering precise pixel alignment, vibrant color output, and uniform brightness. With a 2.5mm pixel pitch, the display offers sharp visuals suitable for closer outdoor viewing distances, making it ideal for premium advertising and commercial displays.

Engineered with IP65 weather protection, this display performs reliably in rain, dust, heat, and humidity, ensuring consistent outdoor performance.
